Technical specifications
System compatible with wall/ceiling thickness from 5/16 to 13/8 " (8 - 35mm).
Type
|
In-wall/in-celling-2-way coaxial
|
Drivers
|
5 "(13 cm) Polyglass Midbass.1" (25mm) AI inverted Dome Tweeter
|
Sensitivity (2.83V/1m)
|
88 dB
|
Frequency range (+/- 3db)
|
65HZ-23 KHz
|
Low frequency point (-6db)
|
56 Hz
|
Nominal impedance
|
8 am
|
Minimal impedance
|
7.3Ω
|
Recommended amplifier power
|
15-100 W
|
Outdoor dimensions (Ø/depth)
|
71/4 "X327/64" (184x87mm)
|
Diameter recess
|
619/64 "(160mm)
|
Depth from the wall
|
315/64 "(82mm)
|
Net weight (with grille at the front)
|
1.45 kg (3.19 LBS)
|
Packaging Dimensions (BxdxH)
|
9 5/8 "X9 5/8" X65/16 "(245x245x161mm)
|
Total weight (with packaging)
|
2.05 kg (4.52 lbs)
|
