Network section File format MP3 / WMA / MPEG-4 AAC, ALAC: up to 96 kHz / 24-bit, WAV / FLAC / AIFF: up to 192 kHz / 24-bit
Ethernet Yes (2 connections)
Airplay yes
Audio specifications channel 8 channel (2 channels x 4)
Minimum speaker tax Power 4 ohm
BTL connection Yes
Speaker output terminal 4 (Euroblock)
Preout terminal 4
Audio- RCA input terminal: 2 (Cut in, AUX), USB: 4
Audio- Exit connection RCA (2 channel by Off): 2 (Cut in, AUX)
Trigger in / out 0/4
Remote control in / out 1/1
Call 4
Nominal output power (1 kHz, 0.9% THD, 2-channel controlled) Normal (4/8 ohms): 90/50 W, Bridge (8 ohm): 100 W
Nominal output power (1 kHz, 0.9% THD, 1CH driven) Normal (4/8 ohms): 100 / 50W, Bridge (8 ohm): 200 W
Dynamic power (20 Hz-20 kHz, 0.08% THD, 2-channel driven, 20 ms burst) Normal (4/8 ohms): 80/40W, bridge (8 ohm): 150 W
Dynamic power (1 kHz, 0.9% THD, 2-channel driven, 20 ms burst) Normal (4/8 ohms): 100/50 W, bridge (8 ohm): 200 W
Dynamic power (1 kHz, 0.9% THD, all channels controlled, 20 ms burst) Normal (4/8 ohms): 80 / 50W, bridge (8 ohm): 170 W
Maximum effective output power [1 -CH driven, 1 kHz, 10% THD] Normal (4/8 ohms): 130 / 65W, bridge (8 ohm): 260 W
Total harmonic distortion [SP Out, 20 Hz-20 kHz, 25 W, 8 ohm] 0.04%, [Pre Out, 20 Hz-20 kHz, 1 v] 0.005%
Frequency range [1 kHz + 0 / -3 dB] Pre out Net / USB in, aux in: 10 Hz-22 kHz, SP Out Net / USB in, aux in: 10 Hz-22 kHz
Signal-to-noise ratio [PRE OUT NET / USB IN] 114 dB, [PRE OUT AUX IN] 108 DB, [SP OUT NET / USB IN] 106 DB, [SP OUT AUX IN] 104 DB
Nominal output level / output impedance [Pre Out L / R, 1 kHz] 2.0 v / 470 ohm
Maximum output level [PRE OUT L / R, 0.9% THD] 4.0 V
Maximum input signal [PRE OUT L / R, 0.9% THD] 2.4 V
Reinforcement [SP OUT 1 V input] 25.8 dB
Input sensitivity [1 w power, 8 ohm] 150 mV, [max (50 w) power, 8 ohm] 1.0 v
Web configuration Yes
Direct mode Yes
Mono Downmix Yes (Play Stereo or Mono Downmix Selectable)
Improved compressed music yes
Volume Adaptive EQ Yes
Support connections for volume control: PRE OUT / SP OUT, Range: Mute, -80 dB ~ 0 dB, Step: 0.5 dB
EQ characteristics [bass] variable width: +6.0 dB ~ -6.0 dB / 0.5 dB step, middle frequency: 350 Hz, [MID] variable width: +6.0 dB ~ -6.0 dB / 0, 5 dB step, middle frequency: 1.1 kHz, [treble] variable width: +6.0 dB ~ -6.0 dB / 0.5 dB step, middle frequency: 3.5 kHz
Bas extension Yes
General power consumption 130 W, [All zones on] No signal condition: 40 W, [All zones off] Doorbell On: 18.2 W, enabled on: 18.2 W
Power consumption in standby network standby out: 0.2 W, network standby on (1 zone): 3.2 w, network standby on (all zones): 6.0 W
Power Management (Auto Power Standby) 5/20 min, 2/4/8/12 hour selectable
Dimensions (b × H × d) mm [table assembly with self-adhesive feet] 437 x 46 x 443 mm; [Table assembly with self-adhesive feet and front plate] 437 x 46 x 453 mm; [Rack mount] 481 x 44 x 443 mm; [Rack mounting with front plate] 481 x 44 x 453 mm;
Weight 6.3 kg
