		RX-A4A	RX-A8A	RX-A6A
Amplifier section	Channel	7.2	11.2	9.2
	Nominal output power (1 kHz, 1Ch driven)	135 W (8 Ohms, 0.9% THD)	185 W (8 Ohms, 0.9% THD)	185 W (8 Ohms, 0.9% THD)
	Nominal output power (20Hz-20KHZ, 2-channel driven)	110 W (8 Ohms, 0.06% THD)	150 W (8 Ohms, 0.06% THD)	150 W (8 Ohms, 0.06% THD)
	Maximum effective output power (1 kHz, 1Ch driven)	165 W (8 Ohms, 10% THD)	220 W (8 Ohms, 10% THD)	220 W (8 Ohms, 10% THD)
	Amplifier with high swivel speed	Yes
Surround sound section	Surround: AI	Yes
	Cinema DSP	Yes (HD3)
	DSP programs	24
	Level adjustment dialog box	Yes
	Virtual attendance speaker	Yes
	Virtual surround-agent speaker	Yes
	Dialog lift	Yes
	Silent Cinema / Virtual Cinema DSP	Yes
	Dolby Atmos	Yes
	Dolby Atmos Height Virtualizer	Yes
	Dolby Truehd	Yes
	Dolby Digital Plus	Yes
	Dolby Surround	Yes
	DTS: X	Yes
	DTS-HD Master audio	Yes
	Auro 3D	N.V.T.	Yes	Yes
audio Aspects	File format	MP3 / WMA / MPEG-4 AAC, Alac: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz	MP3 / WMA / MPEG-4 AAC, Alac: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz	MP3 / WMA / MPEG-4 AAC, Alac: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz
	Pure direct	Yes
	Improved compressed music	Yes
	High resolution music amplifier	Yes
	Ypao Multi -point measurement	Yes with R.S.C. (Reflected sound control), 3D, 64-bit High Precision EQ Calculation and Angle Measurement
	Ypao volume	Yes
	Adaptive DRC (Dynamic Range Control)	Yes
	Initial Volume and Maximum Volume Institution	Yes
	Art. Wedge	Yes
	Bi-IMp Power	Yes
	Audio delay	Yes (0-500 ms)
	Da	384 KHz / 32-bit ESS Hyperstream DAC ES9007S	384 KHz / 32-bit ESS Hyperstream DAC ES9026PRO X2	384 KHz / 32-bit ESS Hyperstream DAC ES9026PRO X1 ES9007S X1
Video aspects	HDMI EARC	Yes
	HDMI AudiorTour Canal	Yes
	HDMI outlet	8k60ab, 4K120AB, 40Gbps (via Future Update)	8k60ab, 4K120AB, 40Gbps (via Future Update)	8k60ab, 4K120AB, 40Gbps (via Future Update)
	HDMI SCHALLING	Yes, up to 8K (via firmware update)
	HDMI UP conversion	AFTER	Yes (analog to hdmi)	Yes (analog to hdmi)
	Dolby Vision	Yes
	HDR 10+	Yes (via firmware update)
	VRR/Allm/QMS/QFT	Yes (via firmware update)
	Video adjustment	AFTER	Yes	Yes
Connectivity	MusicCast Surround	Yes
	HDMI input/output	7/3 (HDMI2.1 / HDCP2.3)
	HDMI CEC	Yes
	USB port	Yes
	Network port:	Yes
	WiFi	Yes (2.4 / 5 GHz)
	AIRPLAY 2	Yes
	Bluetooth	Yes (SBC / AAC)
	Av input in front	USB
	Digital audio-input/output: Optical	2 / 0	3 / 0	3 / 0
	Digital audio-input/output: coaxial	1 / 0	2 / 0	2 / 0
	Analogue audio-entrance exit	4 / 0	6 / 0	6 / 0
	Phono-Entrance	Yes
	XLR terminal	AFTER	Yes	Yes
	Component video input/output	AFTER	1 / 0	1 / 0
	Composite video input/exit	AFTER	2 / 0	2 / 0
	Pre-out	7.2-CH	11.2-CH	11.2-CH
	Headphone output	1
Tuner section	FM/AM-Tuner	Yes (Availability Varies by Region.)
Tuner section	DAB tuner	Yes (Availability Varies by Region.)
User interface	Screen display	Graphical User Interface
	Scene	Scene Plus (8 sets)
	App	Yes (iPhone / iPad / Android Phone / Tablet)
	Web browser control	Yes
	Remote control	Yes
Zone control	Zone 2 audio-Exit	Preout / HDMI
	Zone 3 audio-Exit	AFTER	Leek	Leek
	Zone 4 audio-Exit	AFTER	HDMI	HDMI
	Zone	Zone 2	Zone 2/3	Zone 2/3
	Zone video output	HDMI
	Zone B exit	AFTER	HDMI	HDMI
	Zone-guy	AFTER	Yes	Yes
	RS-232C interface	AFTER
	+12V trigger exit	2
	External (ir) entrance/exit	1 / 1
	Party fashion	Yes
Generally	Standby Power consumption (IR) only)	<0.4 W
	Auto Power Standby	Yes
	Eco-mode	Yes
	Dimensions (B x H x D) in mm	435 x 191 x 442 (with antenna on: 435 x 270 x 442)	435 x 192 x 477 (with antenna on: 435 x 271 x 477)	435 x 192 x 442 (with antenna on: 435 x 271 x 442)
	Weight	16.2 kg	21.4 kg	20.3 kg
