Frequency Response, in-cream (-6db)
35 Hz - 35 kHz
Sensitivity (2.83V @ 1m)
87.5 dB
Minimum impedance
4.9 Ohm @ 170 Hz
Maximum SPL (Single, Free-Field)
106 dB
Power Handling (RMS)
120 W
Recommended Amplifier Requirements
40 - 120 W
Crossover Frequency
2.3 KHz
Port Tuning Frequency
42 Hz
Bass alignment
Bass reflex
Hive II Port System
Drive Unit Complement
1 x 8 "C-CAM RST II MID-BASS Driver
1 x 1 "(25 mm) C-cam gold dome tweeter with ud waveguide II
External Dimensions (Including Grille and Terminals (H x W x D))
375 x 230 x 332 mm (143/4 x 91/16 x 135/64")
External Dimensions (Including Outrigger Feet and Spikes (H x W x D))
AFTER
Weight
9.4 kg (20 lb 12 oz)
