DAC |
ESS ES9028Q2M |
USB AUDIO-ENTRANCE |
USB Type B complies with USB Audio 2.0 |
Digital AUDIO-Inputs |
USB-Drive, Bluetooth (5.1), S/PDIF Coaxial, Toslink optical |
Analogue AUDIO-Tanangs |
Balanced XLR and unbalanced RCA Analogue |
Digital AUDIO-Tanangs |
S/PDIF Coaxial and Toslink optical |
Compatibility |
TOSLINK Optical: 16/24Bit 32-96KHZ PCM, DOP64 S/PDIF Coaxial: 16/24bit 32-192kHZ PCM, DOP64 UPNP: up to 32bit, 768kHZ Local USB-Media: PCM up to 32-bit 768kHZ, DSB, DSB, DSBHZ, DSB, DSBHZ, DSB, DSBHZ,audio: PCM to 32-bit 768KHZ, DSD to X512 Bluetooth: SBC, AAC AirPlay 2, Chromecast built-in, internet radio, Spotify Connect, Tidal Connect, MQA, Qobuz, Deezer, Roon Ready. |
AUDIO- -Formats |
Alac, WAV, FLAC, AIFF, DSD (X512), WMA, MP3, AAC, HE AAC, AAC+, OGG VORBIS |
Ethernet |
10/100Mbit |
Wi-Fi |
Ieee 802.11 AC (2.4GHz / 5GHz) |
Maximum power consumption |
30w |
Power consumption in standby |
<0.5W (Eco), <2W (Network stand-by) |
DIMENSIONS |
430 x 85 x 305 mm (16.9 x 3.4 x 12.2 ") |
WEIGHT |
3.55 kg (7.83 pounds) |
Contents of the box |
CXN100, net cable, operating bus cable, antenna x2, quick -start guide, safety sheet, registration card |
