| Assets |
100W RMS in 8 Ohms @ <1%THD+N, 155W RMS in 4 Ohms @ 1kHZ <1%THD+N |
| Reinforcement |
Class-A/B |
| DAC |
ES9018K2M |
| Pre -amplifier |
Yes |
| Frequency response |
<3HZ-> 40KHZ +/- 1DB |
| Toridal transformer |
Yes |
| Bi-wiring possible |
Yes |
| Analog RCA inputs |
4 Pair |
| Balanced XLR input |
1 Pair |
| S/PDIF TESLINK Input |
2 |
| S/PDIF Coaxial entrance |
1 |
| Asynchronous USB input |
USB Type B in accordance with USB Audio Class 1 or USB Audio Class 2 (user selectable) |
| Bluetooth |
5.0 APTX HD |
| HDMI ARC input |
1 (EARC compatible) |
| Pre -amplifier |
RCA Pre-Out |
| Headphone output |
Yes |
| Subwoofer Exit |
1 x RCA |
| Speaker outputs |
Yes |
| S/PDIF TESLINK Optical |
Toslink: 16/24-BIT 32-96KHZ |
| S/PDIF Coaxial |
Coax SPDIF: 16/24-BIT 32-192KHZ |
| HDMI EARC |
PCM to 24bit/192KHZ |
| USBaudio |
USB Audio Class 1: up to 24-bit 96kHz (asynchronous) | USB Audio Class 2: up to 24-bit 384kHz (asynchronous) and up to DSD-256 |
| Bluetooth |
5.0 A2DP/AVRCP supports SBC, APTX and APTX HD codecs |
| RS232 Check |
Yes |
| THD (Unweighted) |
<0.002% 1KHz in 80% of the nominal power (8 Ohm) | <0.02% 20Hz - 20KHz in 80% of the nominal capacity |
| S/N ratio (Ref 1W) |
> 91DB |
| Crosstal @1khz |
>90 |
| Input sensitivity |
Entrance A2-A4 (unbalanced) 395MV RMS |
| Input impedances |
Entrance A1 (balanced) 100 Kohm entrance A2-A4 (unbalanced) 45 Kohm |
| Damping factor for power amplifier |
> 160 at 1kHz |
| Subwoofer Exit |
1 x RCA |
| Maximum power consumption |
1200 W |
| Standby power consumption |
<0.5W |
| Dimensions (B x H x D) |
115 x 430 x 341 mm (4.5 x 16.9 x 13.4 ") |
| Weight |
12.8 kg (28.2 pounds) |
| In the box |
Power cables, remote control, welcome letter, registration card, safety guide |
