| DAC |
ESS ES9028Q2M |
| Pre -amplifier |
Yes |
| Streammagic version |
Generation 4 |
| Screen display |
4.76 "IPS TFT - 1280 x 569 |
| USB drive entrance |
1 x USB 2.0 |
| S/PDIF TESLINK Input |
1 |
| S/PDIF Coaxial entrance |
1 |
| Asynchronous USB input |
1 |
| Bluetooth |
5.0 with APTX HD |
| HDMI ARC input |
1 (EARC compatible) |
| Analog RCA outputs |
1 Pair |
| S/PDIF output |
1 |
| Toslink output |
1 |
| Balanced XLR output |
1 Pair |
| S/PDIF TESLINK Optical |
16/24Bit 32-96KHZ PCM, DOP64 S/PDIF |
| S/PDIF Coaxial |
16/24bit 32-192kHz PCM, DOP64 |
| HDMI EARC |
PCM to 24bit/192KHZ |
| Local USB media |
PCM to 32-bit 768KHZ, DSD to X512 file system support FAT32, NTFS, EXT2/3/4, Exfat |
| USBaudio |
PCM to 32-bit 768KHZ, DSD to X512 |
| Bluetooth |
5.0 A2DP/AVRCP supports SBC, APTX and APTX HD codecs |
| UPNP |
PCM to 32bit/768KHZ |
| Internet radio |
Yes |
| Tidal Connect |
Yes |
| Connect Spotify |
Yes |
| Qobuz |
Yes |
| Deezer |
Yes |
| Amazon Music |
Yes (via Google Cast) |
| Google Cast |
Yes |
| AIRPLAY 2 |
Yes |
| Roon ready |
Yes |
| Audio formats |
Alac, WAV, FLAC, AIFF, DSD (X512), WMA, MP3, AAC, HE AAC, AAC+, OGG VORBIS |
| Ethernet |
Ieee 802.3, 10 Base-T or 100 BASE-T |
| WiFi |
Ieee 802.11 a/b/g/n/ac (2.4 GHz/5 GHz) |
| RS232 Check |
Yes |
| THD @ 1kHZ 0DBFS |
< 0,0005 % |
| Frequency response |
7Hz to 75kHz +0/-1db |
| Crosstal @1khz |
<-120db |
| Signal-noise ratio (Ref 1W) |
> 120db |
| Maximum power consumption |
30w |
| Standby power consumption |
Network standby:> 2W; Eco mode: <0.5W |
| Dimensions (B x H x D) |
430x90x305mm |
| Weight |
4.1 kilos |
| In the box |
Cable, operating bus cable, antenna x2, quick -start guide, safety sheet, registration card |
