System compatible with wall/ceiling thickness from 5/16 to 19/16" (8 - 40mm)
Type
|
In-wall/in-celling 2-way coaxial
|
Drivers
|
8 "(21 cm) Polyglass Midbass.1" (25mm) AI reverse dome tweeter
|
Sensitivity (2.83V/1m)
|
90 dB
|
Frequency range (+/- 3db)
|
53HZ-23 KHz
|
Low frequency point (-6db)
|
40 Hz
|
Nominal impedance
|
8 am
|
Minimal impedance
|
6.9Ω
|
Recommended amplifier power
|
25-150W
|
Outdoor dimensions (Ø/depth)
|
9 3/4 "X43/8" (248x111mm)
|
Diameter recess
|
813/16" (224mm)
|
Depth from the wall
|
43/16 "(107mm)
|
Net weight (with grille at the front)
|
1.75 kg (3.86 LBS)
|
Packaging Dimensions (BxdxH)
|
12 3/16 "X123/16" X71/4 "(310x310x185mm)
|
Total weight (with packaging)
|
2.60 kg (4.73 lbs)
|
