Monoblock/4/6/8 channel: <5 mA at 14.4 V input Zone: < 1 mA at 14.4 V input
Power consumption (idle)
Monoblock: < 0.89 A at 14.4 V input 4-channel: < 1.15 A at 14.4 V input 6-channel: < 1.32 A at 14.4 V input 8-channel: < 1.60 A at 14.4 V input Zone < : 0.04 A at 14.4 V input
Power consumption (max.)
Monoblock: 87 A 4-channel: 53 A 6-channel: 78 A 8-channel: 104 A Zone: 10 A
Fuse
Monoblock/6/8 channel: 125 A electronic fuse (no replacement required) 4-channel: 85 A electronic fuse (no replacement required) Zone: 16 A electronic fuse (no replacement required)
Min. Copper power/ground wire gauge
Bussmann™ BK/AMI-030 30 A fast acting
Ignition protection (SAE J1171)
Protection circuits
Reverse voltage Input voltage too low/high Overheating Short circuit output
