Marantz CD60

Unit (W x H x D mm)

442 x 129 x 396 cm

Weight

7.5kg

Package dimensions (W x H x D mm)

525×249×511

Panel color

Available colours: Silver/Gold and Marantz Black

Front (middle) panel

Aluminum

Frequency response

USB DSD: 2Hz - 50kHz (-3dB)USB PCM: 2Hz - 50kHz (-1.5dB)CD: 2Hz - 20kHz

Total harmonic distortion

USB DSD: 0.0006% USB PCM 24bit: 0.0005% CD: 0.0015%

Signal to noise ratio

USB DSD: 110dBUSB PCM 24bit: 118dBCD: 118dB

Dynamic range

USB DSD: 110dBUSB PCM 24bit: 118dBCD: 101dB

Line output level

2.2 Vrms

Headphone output level

28mW / 32 ohms

Power consumption

38W

at Standby

0.3W

HDAM

New HDAM + HDAM-SA2

Power transformer

Egg

Headphone amplifier

High slew rate op-amp + HDAM-SA2

H/P Amp Gain Setting

Yes (Low / Mid / High)

Digital filter

Filter 1, 2 selectable

CD compatibility

CD / CD-R/RW / WMA / MP3 / AAC

Data disc compatibility

DSD/WAV/ALAC

Fixed analog output (RCA)

1 (Gold plated)

Optical input/output (maximum support)

0 / 1

Coaxial input/output (maximum support)

0 / 1

Headphone output

1

Remote Control Bus Terminal

Yes (RC-5 In/Out) w/ External/Internal Select Switch

USB A

1 (front) mass storage class 5V/1A

Support format

FAT 16/32

USB-A: FLAC / WAV / AIFF / ALAC / DSD

Yes / Yes / Yes / Yes

DSD Native playback

Yes

USB firmware update

Yes

Remote control

System remote control (amplifier and CD player control)

Unit control (button)

POWER, Play/Pause, Stop, Input, Open/Close, Fwd, Rev

Unit control (button)

1Phones level

Dimmer for Front Display

Bright / Dim / Dark / Off

Control with app via network player (use remote control bus)

Yes

Last function memory

Yes

Timer Play (requires external audio timer)

YesOn/Off selectable in menu

Automatic standby mode

Yes

Other

Stereo RCA cable x1Remote connector cable x1

Accessory box

Yes

Battery

Yes (AAA x2)

Power cable

Yes
