Channels2
-
PSU TransformerToroidal
-
Speaker A / bNo
-
Speaker TerminalsMarantz SPKT-1+
-
Number of Terminals2
-
Power Output (8 /4 Ohm RMS)60 W / 80 W
-
TopologyClass A/B
Audio Components and Technologies
-
Current Feedback TopologyYes
-
Hdam VersionSA3, SA2
-
High grade Audio ComponentsYes
-
Customized ComponentsYes
-
Symmetric PCB LayoutYes
-
Aluminum Extrusion Heat SinkYes
-
Copper Plated ChassisNo
-
Marantz Musical Digital FilteringNo
-
Linear Drive Power SupplyYes
-
Bi-Amm and Multichannel OptionNo
-
Shottky diodesYes
DAC
-
Digital InputsCoaxial, Optical, USB-A
-
Max PCM Sample Rate192 KHz / 24-bit
-
Max DSD Sample RateDSD 4x (11.2 MHz)
-
HDMI1 ARC
Heos
-
Streaming TechnologiesBluetooth, AirPlay 2, Roon Ready, Spotify Connect, Tidal Connect
-
Streaming Services (subject to change and local availability)Tidal (Hi Res), Deezer (Hi Res), Amazon Music HD, Pandora, Tunein, Iheartradio, Soundcloud, SiriusXM, AWA, MOOD: MIX, QPLAY, SONY HIRES
-
Heos Multiroom and StreamingYes
-
Lossy FormatsMp3, wma, aac
-
Lossless formatsDSD/DSF, FLAC, Alac, WAV
-
Gapless PlaybackYes
-
Heos appiOS, Android
Network
-
Wi-Fi / Wired LANYES / YES
Other
-
DisplayLow-Noise Oled Monochrome
Prime city
-
Phono EQMm Standard
-
Tuner: FM / AMNo
-
Audio AdjustmentsYes
-
Power Amp DirectNo
-
Balanced in / outNo / no
-
Preamp outputs1
-
Subwoofer Output1 Mono
-
Headphone outYes
Specifications
-
Frequency response5 HZ-100 KHz
-
Total Harmonic Distortion0.02 %
-
Damping factor100<
-
Input Sensitivity: mm1.9 MV / 47 KOHM
-
Signal to Noise Ratio: MM/MC87 dB / -
-
Input Sensitivity: High Level190 MV / 20 Kohm
-
Signal to Noise Ratio: High Level113DB
-
Treble control± 10 dB at 15kHz
-
Bass Control± 10 dB at 50Hz
-
Metal Front PanelYes
-
Power Consumption in W220
-
Standby consumption in w0.3
-
Auto Power OffYes
-
Detacable Power CableYes
-
Remote controlRC006PM
-
System Remote FunctionYes
-
Maximum dimensions (W x D x H) mm442 x 431 x 129
-
Carton Maximum Dimensions (W x D x H) mm527 x 517 x 255
-
Carton Weight (inc. Product) in kg15.5
-
Maximum Dimensions (W x D x H) in17.4 x 17 x 5.1
-
Weight in LBS28.1
-
Carton Maxim Dimensions (W x D x H) in20.8 x 20.4 x 10.1
-
Carton Weight (inc. Product) in LBS34.3
