| Front Surround System |
| General |
Drivers |
Front L/R: 4.6 cm (1.8 ") Cone × 4, tweeter: 2.5 cm (1") Dome × 2, Built-in subwoofer: 7.5 cm (3 ") Cone × 2 |
| Output power |
120 W (front L/R: 30 W × 2-CH, Built-in subwoofer: 60 W) |
| Power Consumption |
23 W |
| Standby power consumption |
0.3 W (HDMI Control Off, Bluetooth Standby Off), 0.6 W (HDMI Control ON, Bluetooth Standby On) |
| Dimensions (W x H x D) |
Installing the unit in front of a TV: 910 × 68 × 133 mm (35-7/8 "× 2-5/8" × 5-1/4 "), mounting the unit on a wall with spacers: 910 × 66 × 139 mm (35-7/8 "× 2-5/8" × 5-1/2 ") |
| Weight |
3.9 kg (8.6 LBS) |
| Input / output |
HDMI |
1 Out (EARC) |
| Digital Optical |
Yes |
| Subwoofer output |
Yes |
| Analog Audio |
No |
| HDMI |
EARC/ARC |
EARC/ARC |
| CEC |
Yes |
| Car LIP-SYNC |
No |
| Sound Technology |
Surround Technology |
Dolby Atmos |
| Surround fashion |
Stereo, standard, movie, game |
| Compressed Music Enhancer |
No |
| Bass Extension |
Yes |
| Audio Formats |
Dolby Digital |
Yes |
| Dolby Pro Logic II |
No |
| DTS Digital Surround |
No |
| Connectivity |
Wireless Music Streaming |
No |
| Wi-Fi |
No |
| MusicCast Surround |
No |
| Airplay |
No |
| Bluetooth Version/Profile |
Version: Ver 5.1 / Profiles: A2DP / codecs: SBC, AAC |
| Bluetooth Maximum Communication Range |
Approx. 10 m; 33ft (Without Obstructions) |
| Wireless Subwoofer |
No |
| Other features |
App control |
Yes (Sound Bar Remote) |
| Learning function |
No |
